New types of solar cells will more than likely consist partly of perovskites. Eight years ago perovskites emerged as a new and promising material to absorb sunlight and generate electricity, stirring up the entire research field. Today perovskites are almost equally efficient as the silicon solar cells that have been developed over a time span of 60 years. Since perovskites absorb a different part of the spectrum than silicon, combining both materials in a so-called tandem solar cell should in theory lead to the conversion of a much larger part of the sun’s emitted energy and hence to the generation of more electricity.
Weather conditions
The researchers developed their own model to predict the expected electricity yield of these tandem solar cells under realistic weather conditions. Standard test conditions for solar cells mimic a sunny summer day in the northern hemisphere, with an average temperature of 25 degrees Celsius. However, many solar cells operate in cloudy climates, such as the Dutch one. In these weather conditions the combination of current record cells turns out to be hardly more efficient than cells consisting solely of silicon. The researchers used measured temperatures, irradiances, and solar spectra to predict the performance of these cells in Utrecht (the Netherlands) and Denver (United States). The model also predicts which improvements are necessary for perovskites to live up to their promise of reaching solar cell efficiencies higher than 30 percent in combination with silicon.
Too cloudy for a tandem
Thus, the researchers have shown that in the Netherlands, a country with many rainy and cloudy days even in the summer, tandem cells turn out to be hardly more efficient than current conventional silicon solar cells. This is true even when the cells are made from the best perovskite and silicon solar cells currently available. ‘This has been a surprising finding,’ Moritz Futscher, lead author of the study, says. ‘We have always thought that tandem cells operate at lower efficiency under low-light conditions, but we were surprised that the effect is this large.’
Besides this slightly distressing finding, the researchers also report how the perovskite cells could be improved to actually make tandem solar cells much more efficient than cells consisting solely of silicon. Their model shows that an efficiency increase of up to 14 percent could be realised by further optimisation of the perovskite quality, the electrical contacts, and by optimising light management in the stacked perovskite/silicon cell. ‘In the light of the rapid developments in the past few years, I am very optimistic that we will see largely improved perovskite cells, but it does require a large, concerted, and focussed research effort,’ says Bruno Ehrler, who directed the study.
Reference
Moritz H. Futscher, Bruno Ehrler, Modeling the Performance Limitations and Prospects of Perovskite/Si Tandem Solar Cells under Realistic Operating Conditions, ACS Energy Letters, (2017) | DOI: 10.1021/acsenergylett.7b00596
